Application: Extraction hose for air, dust, powder, sawdust or chemical vapours. The very flexible and wear-resistant hose can still transport the full volume of material even when it is bent, because the hose wall flexes outwards.

Temperature range: -25°C to +85°C
Structure: Polyurethane, transparent, with embedded impact-resistant PVC spiral, smooth inner surface, corrugated on the outside, with external stranded copper wire
Vacuum: 0.3 bar

Application: This hose is also suitable for gravel and mud. Sturdy design, with notch- and wear-resistant core.
Temperature range: -30°C to +80°C
Inner core: Para rubber, brown, smooth
Outer cover: SBR/NR, black, textured fabric

Inserts: Steel wire spiral and stranded copper wire
Vacuum: 0.8 bar
Operating pressure: 4 bar
Bursting pressure: 12 bar

Abrasion resistance:
Inside 70 mm³ as per DIN 53516, outside 90-110 mm³ as per DIN 53516

Application: Particularly suitable for stone chippings, soda and quartz sand Sturdy design with notch- and wear-resistant core
Temperature range: -30°C to +80°C
Inner core: NR, black, smooth
Outer cover: SBR, black, textured fabric

Inserts: Steel wire spiral and two crossed stranded copper wires
Vacuum: 0.8 bar
Operating pressure: 10 bar
Bursting pressure: 30 bar
Electrical resistance:
< 10000000 ohms

Application: Extraction hose for gravel, sand, glass and grain. Retains its shape even when exposed to extreme abrasion and high vacuum. Resistant to oil and petrol

Temperature range: -40°C to +90°C, short-term spikes up to +125°C
Structure: Polyurethane, transparent, with embedded steel wire spiral, smooth inner surface, corrugated on the outside
Bending radius: 2.7 x inside diameter

Application: A hose suitable for a large number of chemicals, including hydrocarbons, acids and lyes.
Temperature range: Up to max. +66°C
Inner core: Cross-linked polyethylene, smooth

Outer cover: EPDM, green, textured fabric
Inserts: Steel wire spiral and stranded copper wire
Vacuum: 9 metres water column
Operating pressure: 15 bar
Bursting pressure: 45 bar

Application: Hose for water and air, but resistance to chemicals is limited Physiologically harmless.

Temperature range: -20°C to +60°C
Inner core: PVC, transparent, smooth
Outer cover: PVC, transparent, smooth
Standard: 95 / 3 / CE

Application: Acetylene and oxygen
Inner core: Synthetic rubber, black, smooth
Outer cover: Synthetic rubber
Operating pressure: 20 bar

Bursting pressure: 60 bar
Standard: EN 559
Oxygen: blue, smooth
Acetylene: red, smooth

Application: Hot air, smoke, gas, steam and engine breathers. Unsuitable for solids.
Temperature range: -40°C to +120°C, brief periods up to +150°C

Structure: Santoprene, black, with embedded steel wire spiral
Bending radius: 1 x inside diameter

Application: For watery salt solutions and hot water. The hose has wear-resistant kink protection fins.
Temperature range: -40°C to +120°C

Inner core: Synthetic rubber, black, smooth
Outer cover: Synthetic rubber, red/black, stripes lengthwise, smooth

Application: Vinyl hose for irrigation and draining water.
Temperature range: -10°C to +60°C

Inner core: PVC, black, smooth
Outer cover: PVC, blue, smooth

Application: Water, fertiliser and seed. Hose with very flexible design.
Temperature range: -15°C to +60°C

Structure: Plastic material, dark green, transparent with embedded white PVC spiral
Vacuum: 0.6 bar

Application: Gases, water, light lyes and acids. The hose is resistant to ozone and heat.
Temperature range: -30°C to +135°C

Structure: EPT moulded hose, corrugated inside and out
Operating pressure: 1.5 bar
Length: 1 metre

Application: Dairy products, animal and vegetable fats and oils.
Temperature range: -25°C to max. +80°C, brief periods up to +120°C for cleaning
Inner core: Butyl, white, ultra smooth, taste and odour free

Outer cover: EPDM/NBR, blue, textured fabric
Inserts: Textile fabric
Operating pressure: 10 bar
Bursting pressure: 30 bar
Standard: FDA quality
